API 8A/8C Drill Pipe Hydraulic Elevators Type DDZH
- Hydraulic Elevators
- Hydraulic Elevators Type DDZH
- API 8A/8C Drill Pipe Hydraulic Elevators Type DDZH
- Product description: Hydraulic Elevators;Hydraulic Elevators Type DDZH;API 8A/8C Drill Pipe Hydraulic Elevators Type DDZH
Product introduction
High Quality API8A/8C Hydraulic Elevators type DDZH 2 3/8''-6 5/8''
Specification
1. Type DDZH hydraulic elevators are center latch elevators
2. handle drilling pipe, drill collar, casing and tubing with the hydraulic control system through changing the bushing.
3. makes the operation more convenient, effectively reduces the workers’ labor intensity and improves the work efficiency
4. realize remote control and make the use safer and more reliable
5.Standard: API Spec 8C Specification for Drilling and Production Hoisting Equipment
Main Technical Parameters
|
Model |
Tubular & Size(in) |
Rated Cap. (Short tons) |
|||
|
DP with 18°taper |
Casing |
DC |
Tubing |
||
|
DDZH-250 |
23/8-5 |
41/2-5 |
31/8-51/4 |
23/8-41/2 |
250 |
|
DDZH-350 |
23/8-65/8 |
41/2-7 |
31/8-63/4 |
23/8-51/2 |
350 |
|
DDZH-500 |
23/8-65/8 |
41/2-7 |
31/2-63/4 |
/ |
500 |
